Hot Racing TD110X06 Aluminum Heavy-Duty Big Bore Shock Set – 2-Piece, 110mm Length

Description

Hot Racing 110mm big bore threaded body aluminum shocks for many TRA and other 1/10th scale off-road vehicles using 110mm shocks

FEATURES:

– CNC machined 6061-T6 billet aluminum shock bodies, collars, caps, and spring retainers
– “Big Bore” threaded shock bodies
– CNC machined 11mm Delrin pistons
– 3.5mm stainless steel shock shafts
– Gunmetal and blue anodized aluminum components
– Vented shock caps with bladder seals for consistent rebound dampening
– Threaded shock collars with o-rings to prevent unwanted movement
– Composite plastic lower shock ends with aluminum balls
– Fully assembled, just add shock oil and bleed

YOU WILL RECEIVE:

– Two (2) assembled shocks
– Two (2) M3x20mm flat head cap screws
– Two (2) M3x18mm button head cap screws
– Two (2) 3mm countersunk washers
– Two (2) 5.9 hollow balls
– Four (4) 1.5mm thick spacers
– Four (4) 3mm thick spacers

REQUIREMENTS:

– Silicone shock oil of modeler’s choice and bleeding per the typical bladder shock bleeding procedure
– Best used with Team Associated shock Green Slime grease or shock o-ring grease when rebuilding lower seal
– Snap ring pliers when rebuilding lower seal

SPECIFICATIONS:

– Extended length: 110mm
– Compressed length: 75mm
– Overall length: 120mm
– diameter: 19mm
– Spring: ~5.8lb/in, 1.54mm wire, 14 turn dual rate, 19.3mm OD, 73mm long

COMMENTS:

– Use spacers as need for installation
– Can be used with optional Hot Racing springs: SLF63FS261 (progressive), SLF63MR268 (linear), SLF63RS286 (progressive)
– See Hot Racing TD8100X06 for an eight (8) pack of 100mm shocks
– Accepts optional Hot Racing silicone shock boot RDP34201
– Replacement parts are Hot Racing: RTD910BN (shock ends), RTD910RB (pistons and o-rings), RTD1010X (bladders and lower seals)
