Injora INJS11 High-Torque Servo with Precision Brass Mount and Horn – Compatible with Redcat Ascent-18 (1:18 Scale)

Description

INJORA High Voltage Large Torque Metal Gear Digital Micro Coreless Servo for 1/18 RC Crawler Redcat Ascent-18

Note: The servo horn is only compatible with INJORA INJS11 Servo

Features:

• Two-position adjustable designed servo mount
• Provide extra weight and lower the centre of gravity
• Easy to install, just replace the stock plastic parts
• High quality CNC machined brass, corrosion resistant and durable
• Adds stylish, unique and premium touch to your vehicle’s appearance

Servo Specifications:

• Part Number: INJS11
• Operating Voltage: 6V-8.4V
• Torque(6V): 8kg-cm/111oz-in
• Speed(6V): 0.106″/60°
• Torque(7.4V): 9.5kg-cm/132oz-in
• Speed(7.4V): 0.085″/60°
• Torque(8.4V): 11kg-cm/153oz-in
• Speed(8.4V): 0.074″/60°
• RC Angle: 90°±5
• 500-2500μs Angle: 180°± 5
• Motor: Coreless
• Gears: Stainless Steel
• Spline: 25T
• Bearing: 2BB
• Size: 23*12*26.5mm
• Weight: 21g

Servo Mount Specifications:

• Part Number: ASC18-13
• Material: Brass
• Weight: 10g (0.022lb)

Servo Horn Specifications:

• Material: Brass
• Weight: 2.5g
• Screw hole size: M2
