RC4WD 750K Crawler Brushed Motor – 16-Tooth Pinion, 3.5mm Bullet Connectors (Model RC4ZE0074)

Description

Overview

Specifications:

• Custom Made 750 Steel Case
• Chrome Plated Case
• Build in Capacitor for Minimizing Glitch
• High Torque Magnet and Rotor
• Tuned for Rock Climbing and Scale Driving
• Body OD: 1.65 in (42mm)
• Length: 2.36 in (60mm)
• Output Shaft Length: 0.67 in (17mm)
• Output Shaft OD: 0.2 in (5mm)
• Weight: 9.52 oz (270g)

At No Load

• Speed: 15050 RPM
• Current: 1.88 A

At Stall (Extrapolated)

• Torque: 2100 mN-m
• Current: 30.8 A

At Maximum Efficiency

• Efficiency: 56.41%
• Torque: 416.0 mN-m
• Speed: 12067 RPM
• Current: 7.61 A
• Output: 51.5 Watts

At Maximum Power Output

• Output: 81.8 Watts
• Torque: 1049.5mN-m
• Speed: 7525 RPM
• Current: 16.34 A
