| Length (overall): | 37.5 inches (953 mm) |
|---|---|
| Length (chassis): | 34.0 inches (863 mm) |
| Front Track: | 9.8 inches (245 mm) |
| Rear Track: | 9.8 inches (249 mm) |
| Ground Clearance: | 3.14 inches (80 mm) |
| Weight: | 10.7 pounds (4.83 kg) |
| Height (overall): | 11.9 inches (303 mm) |
| Wheelbase (front & intermediate axle): |
18.6 inches (471 mm) |
| Wheelbase (front & rear most axle): |
23.7 inches (603 mm) |
| Approach Angle: | 60° |
| Departure Angle: | 55° |
| Breakover Angle: | 57° |
| Front Shock Length: | 3.54 inches (90 mm) |
| Rear Shock Length: | 3.54 inches (90 mm) |
| Front Wheels: | 2.2 x 1.02 inches (56 x 26 mm) |
| Rear Wheels: | 2.2 x 1.02 inches (56 x 26 mm) |
| Battery Tray: | 158.75 L x 47 W x 23/26 mm H |
|---|---|
| Front Tires: | 4.64 x 1.89 inches (118 x 48 mm) |
| Rear Tires: | 4.64 x 1.89 inches (118 x 48 mm) |
| Hex Size: | 12 mm |
| Speed Control: | XL-5 HV |
| Motor (electric): | Titan® 21T Reverse Rotation |
| Transmission: | 2-speed High/Low, Remote Shifting |
| Gear Pitch: | 32P |
| Differential Type: | 4 Gear, Remote Locking |
| Chassis Structure / Material: | Steel Ladder Frame with Nylon Composite Crossmembers |
| Brake Type: | Electronic “Hill Hold” |
| Drive System: | Shaft-Driven 6WD |
| Steering: | Chassis Mounted Servo |
| Servo: | 2075X Metal Gear |
| Transmitter: | TQi™ 2.4GHz 4-Channel Transmitter |
| Receiver: | 6533 |
| Skill Level: | 1 |
BUILT TO HAUL
The Ultimate RC Hauler is the largest TRX-6® model with an extra long 23.7″ (603mm) wheelbase and oversize bed to haul your 4-Tec models in style. The highly detailed truck features deep gloss black paint over molded black chrome body accessories for an intimidating look to match its big rig attitude.
DETAILED BED AND LIGHTS
Adjustable wheel chocks with tie-down bands on the Ultimate Hauler’s tow bed accommodate any 4-Tec 2.0 or 3.0 model and keep precious cargo secure. A powerful and true-to-scale LED lighting system with 25 individual lights makes twilight adventures a reality.
TRX-6 CAPABILITY
Built on the supremely capable TRX-6 platform, the Ultimate RC Hauler uses six drive wheels to get into the action with trail-conquering grip of three remote-locking T-Lock™ differentials to get back out. A remote-shifting high/low range transmission amplifies the motor’s torque down low to move heavy loads while still providing ample cruising speed when unloaded.
FACTORY-INSTALLED PRO SCALE WINCH
The Ultimate RC Hauler now includes a Traxxas Pro Scale Winch standard, raising the scale realism to a new level. Utilize the winch to pull and secure your 4-Tec models onto the Hauler’s detailed bed with the included remote. The winch is pre-wired and ready to go out of the box.
