Yeah Racing Hackgear Drift-Spec Low-Profile Digital Servo – High-Speed, Blue

Description

Feature:

• For: 1/10 Drift, On Road RC
• Material: Plastic
• Premium Value at lower price point
• Long wears titanium gear and copper gears
• Digital precision provides great accuracy and performance
• Ball bearing-supported output 25T shaft
• Compatible with all types of Radio system

Specification:

• Type: Digital
• Operating Voltage Range: 4.8 -6.0Volts DC
• Bearing Type:Dual Ball Bearings
• Speed (s/60¢X@4.8V/6.0V): 0.10/ 0.08
• Torque oz./in. (4.8V/6.0V): 76/97
• Torque kg./cm. (4.8V/6.0V): 5.5/7
• Size: 40.9mm x 20mm x 25.2mm
• Motor Type: Coreless
• Operating Temperature Range(¢J): -10¢X to 50¢X
• Dead Band Width: 2µs
• Potentiometer Type: Rotating(Max.220¢X)
• Connector Wire Length: 11.8 in. / 300 mm.
• Connector Wire Gauge: 25 AWG Black Wire
• Connector Type: Futaba
• Gear Type: Titanium Gears + Copper Gears
• Frequency: 330Hz
• Shaft: 6mm 25T

Include:

• Hackgear Drift Spec Low Profil Servo (1 pc)
• Servo Horns (2 pcs)
• Mounting Hardware (1 pack)
